Airobot V6

• Filters: Exhaust: ePM10 55% (M5), outdoor air: ePM1 55% (F7)
• Material: Expanded Polypropylene (EPP)
• Housing: Sheet metal, powder-coated white or black
• Ducting: 200 mm
• Condensate drain: HRV: 32 mm, water trap included. ERV: not equipped and not required under normal conditions
• Power supply: 1~230 VAC, EU plug, maximum power 2.1 kW (10A circuit breaker)
• Fan power 2 x 170 W
• Pre-heater: Integrated, 0-100% controllable PTC heater, nominal power of pre-heater (varies depending on external temperature) kW: 1.5 kW
• Ventilated air -20 °C to +50 °C, maximum extract relative humidity 80%
• Ambient temperature +5 °C to +40 °C (HRV), -20 °C to +40 °C (ERV)
• Dimensions: 590 x 699 x 783 mm
• Weight: 50 kg
• Compliance: EN 60335-1, EN 61000-6-3, EN 61000-6-1, Ecodesign Directive 2009/125/EC
• Warranty 2-year standard, 2 additional years under special conditions

• High-efficiency EC Fans

• Constant flow technology by measuring fan pressure to maintain balanced airflow in all conditions automatically (Optional)

• Speed continuously adjustable 0-100% in automatic mode, incrementally adjustable 0-10 in manual mode

• Integrated sensors: CO2, VOC, 4 air temperature and humidity sensors
• Occupancy sensing and energy-saving mode – Airobot senses room occupancy by combining data from several sensors. It activates energy-saving mode automatically when necessary.
• Integrated frost protection (preheater), nominal power 1.35 kW, PTC 0-100% control
• Humidity detection – whenever the unit senses a sudden increase in humidity, it switches to a higher speed
• Automatic summer bypass
• Autonomous control – smart motor control ensures pleasant indoor air and maximum energy efficiency
• Overpressure mode – temporarily switches the unit to pressurize indoor air; can be automated with a pressure sensor to react to a stove hood, for example
• Boost mode – temporarily switches the unit to maximum speed to quickly ventilate the space

• iOS and Android mobile applications – access all features and settings, no wall-mounted remote needed (requires network connection)

• Wall-mounted remote VE1: optional

• Home automation: Modbus RTU and Modbus TCP (LAN only)

• Connectivity: LAN and Wi-Fi (2.4 GHz)

The V6 model is supplied with Type  R duct connections by default. The connections can be switched to Type  L on-site if needed.

SUP – Supply air to the room

ETA – Extract air from the room

ODA – Outside air

EHA – Exhaust air to outside

Airobot products listed in Magicad Cloud platform

Airobot V4 and V6 is not yet added to Magicad, this should be completed by end of 2025. Meanwhile download V4 and V6 REVIT models from here.

Click here to access files and manuals
